Topics
Replies
amch
18 Feb 2021, 14:10
( Updated at: 18 Feb 2021, 14:26 )
RE:
PanagiotisCharalampous said:
Hi Christian,
Can you please post the complete cBot and Indicator source codes and steps to reproduce the problem?
Best Regards,
Panagiotis
Please find below the indicator as well as the cBot:
using System;
using cAlgo.API;
using cAlgo.API.Internals;
using cAlgo.API.Indicators;
using cAlgo.Indicators;
using UnscentedKalmanFilter;
using primeAlgoCore.Enums;
namespace cAlgo
{
[Indicator(IsOverlay = true, TimeZone = TimeZones.UTC, AccessRights = AccessRights.None)]
public class iUnscentedKalmanFilterRenko : Indicator
{
[Parameter("Source")]
public DataSeries Source { get; set; }
[Parameter("MA Periods", DefaultValue = 14, MinValue = 1, MaxValue = 55)]
public int Periods { get; set; }
[Parameter("Threshold", DefaultValue = 0.00015)]
public double Threshold { get; set; }
[Parameter("Brick size", DefaultValue = 0.0005)]
public double BrickSize { get; set; }
[Output("Neutral", LineColor = "Gray")]
public IndicatorDataSeries Neutral { get; set; }
[Output("Buy", LineColor = "LimeGreen", Thickness = 2, PlotType = PlotType.DiscontinuousLine)]
public IndicatorDataSeries Buy { get; set; }
[Output("Sell", LineColor = "Red", Thickness = 2, PlotType = PlotType.DiscontinuousLine)]
public IndicatorDataSeries Sell { get; set; }
[Output("Renko", LineColor = "Blue", Thickness = 2, PlotType = PlotType.DiscontinuousLine)]
public IndicatorDataSeries Renko { get; set; }
private UKF filter;
private IndicatorDataSeries filterIndi;
public MovingAverage filterMA;
public TrendType CurrentTrend;
private int CountBars;
private double renkoValue = 0;
public TrendType renkoTrendType = TrendType.None;
public double prevUKF;
public double prevUKF2;
private int CurrentIndex = -1;
private int ukfIndex = -1;
protected override void Initialize()
{
filter = new UKF();
filterIndi = CreateDataSeries();
filterMA = Indicators.MovingAverage(filterIndi, Periods, MovingAverageType.Hull);
CountBars = 0;
}
public override void Calculate(int index)
{
CurrentIndex = index;
if (CurrentIndex == 0)
{
filter.Update(new[]
{
Source[0]
});
ukfIndex++;
filterIndi[ukfIndex] = filter.getState()[0];
return;
}
if (CurrentIndex == 1)
{
ukfIndex++;
filter.Update(new[]
{
Source[0]
});
filterIndi[ukfIndex] = filter.getState()[0];
Neutral[CurrentIndex] = filterMA.Result[CurrentIndex];
renkoValue = Bars.ClosePrices[CurrentIndex];
//Renko[CurrentIndex] = renkoValue;
if (Bars.ClosePrices[CurrentIndex] - Bars.ClosePrices[CurrentIndex - 1] > 0)
renkoTrendType = TrendType.Up;
else if (Bars.ClosePrices[CurrentIndex] - Bars.ClosePrices[CurrentIndex - 1] < 0)
renkoTrendType = TrendType.Down;
return;
}
double renkoUpperLimit = RenkoUpperLimit();
double renkoLowerLimit = RenkoLowerLimit();
if (CurrentIndex > CountBars)
{
double lastPrice = Bars.ClosePrices[CurrentIndex];
if (lastPrice > renkoUpperLimit && renkoTrendType == TrendType.Up)
{
renkoValue += Math.Floor((lastPrice - renkoValue) / BrickSize) * BrickSize;
Renko[CurrentIndex - 1] = renkoValue;
SetKalmanFilter();
}
else if (lastPrice < renkoLowerLimit && renkoTrendType == TrendType.Up)
{
renkoValue -= Math.Floor((renkoValue - lastPrice) / BrickSize) * BrickSize;
renkoTrendType = TrendType.Down;
Renko[CurrentIndex - 1] = renkoValue;
// LinesSeries[3].SetMarker(1, new IndicatorLineMarker(Color.Red, upperIcon: IndicatorLineMarkerIconType.FillCircle));
SetKalmanFilter();
}
else if (lastPrice > renkoUpperLimit && renkoTrendType == TrendType.Down)
{
renkoValue += Math.Floor((lastPrice - renkoValue) / BrickSize) * BrickSize;
renkoTrendType = TrendType.Up;
Renko[CurrentIndex - 1] = renkoValue;
// LinesSeries[3].SetMarker(1, new IndicatorLineMarker(Color.Green, bottomIcon: IndicatorLineMarkerIconType.FillCircle));
SetKalmanFilter();
}
else if (lastPrice < renkoLowerLimit && renkoTrendType == TrendType.Down)
{
renkoValue -= Math.Floor((renkoValue - lastPrice) / BrickSize) * BrickSize;
SetKalmanFilter();
Renko[CurrentIndex - 1] = renkoValue;
}
else
{
Renko[CurrentIndex - 1] = renkoValue;
Neutral[CurrentIndex - 1] = Neutral[CurrentIndex - 2];
Buy[CurrentIndex - 1] = Buy[CurrentIndex - 2];
Sell[CurrentIndex - 1] = Sell[CurrentIndex - 2];
}
CountBars = CurrentIndex;
}
}
private void SetKalmanFilter()
{
filter.Update(new[]
{
Source[CurrentIndex]
});
ukfIndex++;
filterIndi[ukfIndex] = filter.getState()[0];
Neutral[CurrentIndex - 1] = filterMA.Result[ukfIndex];
prevUKF2 = prevUKF;
prevUKF = Neutral[CurrentIndex - 2];
Buy[CurrentIndex - 1] = double.NaN;
Sell[CurrentIndex - 1] = double.NaN;
double delta1 = filterMA.Result[ukfIndex] - filterMA.Result[ukfIndex - 1];
double delta2 = filterMA.Result[ukfIndex] - filterMA.Result[ukfIndex - 2];
//Core.Loggers.Log($"KF Value: {Settings.FirstOrDefault(i => i.Name.Equals("Sharpness")).Value}", LoggingLevel.System);
if ((Math.Abs(delta1) > Threshold) || (Math.Abs(delta2) > Threshold))
{
if (delta1 > Threshold || delta2 > Threshold)
{
Buy[CurrentIndex - 1] = Neutral[CurrentIndex - 1];
CurrentTrend = TrendType.Up;
}
else if (delta1 < -Threshold || delta2 < -Threshold)
{
Sell[CurrentIndex - 1] = Neutral[CurrentIndex - 1];
CurrentTrend = TrendType.Down;
}
}
}
private double RenkoUpperLimit()
{
return renkoTrendType == TrendType.Up ? renkoValue + BrickSize : renkoValue + 2 * BrickSize;
}
private double RenkoLowerLimit()
{
return renkoTrendType == TrendType.Up ? renkoValue - 2 * BrickSize : renkoValue - BrickSize;
}
}
}
using System;
using System.Linq;
using cAlgo.API;
using cAlgo.API.Indicators;
using cAlgo.API.Internals;
using cAlgo.Indicators;
using cAlgo;
using primeAlgoCore.Enums;
namespace cAlgo.Robots
{
[Robot(TimeZone = TimeZones.UTC, AccessRights = AccessRights.None)]
public class primeAlgoUFK : Robot
{
[Parameter("Source")]
public DataSeries Source { get; set; }
[Parameter("MA Periods", DefaultValue = 14, MinValue = 1, MaxValue = 55)]
public int Periods { get; set; }
[Parameter("Threshold", DefaultValue = 0.00015)]
public double Threshold { get; set; }
[Parameter("Brick size", DefaultValue = 0.0005)]
public double BrickSize { get; set; }
[Parameter("Quantity (Lots)", DefaultValue = 1, MinValue = 0.01, Step = 0.01)]
public double Quantity { get; set; }
private const string label = "Sample Trend cBot";
//private TrendType CurrentFastTrend;
private const double TrailingStopTrigger = 0;
private const double TrailingStopStep = 0;
private const double StopLossPips = double.NaN;
private const double TakeProfitPips = double.NaN;
public iUnscentedKalmanFilterRenko UnscentedKalman;
protected override void OnStart()
{
UnscentedKalman = Indicators.GetIndicator<iUnscentedKalmanFilterRenko>(Source, Periods, Threshold, BrickSize);
}
protected override void OnTick()
{
// Put your core logic here
}
protected override void OnBar()
{
// Print("{0:0.00000} {1:0.00000}", SlowKalmanRenko.Neutral.LastOrDefault(), FastKalmanRenko.Neutral.LastOrDefault());
// Print(Bars.TickVolumes.Last(1));
if (double.IsNaN(UnscentedKalman.Renko.Last(0)) || double.IsNaN(UnscentedKalman.Renko.Last(1)))
return;
if (UnscentedKalman.Renko.Last(0) == UnscentedKalman.Renko.Last(1))
return;
//Print("Bar: {0} {1} Renko: {2:0.0000(0)} {3:0.0000(0)} Renko Trend: {4}", Bars.OpenTimes.Last(), Bars.OpenPrices.Last(), UnscentedKalman.prevUKF2, UnscentedKalman.prevUKF, UnscentedKalman.renkoTrendType.ToString());
// SetFastTrend();
var longPosition = Positions.Find(label, SymbolName, TradeType.Buy);
var shortPosition = Positions.Find(label, SymbolName, TradeType.Sell);
//var currentSlowMa = SlowKalmanRenko.Neutral.Last(1);
//var currentFastMa = FastKalmanRenko.Neutral.Last(1);
//var previousSlowMa = SlowKalmanRenko.Neutral.Last(2);
//var previousFastMa = FastKalmanRenko.Neutral.Last(2);
//Print("{0:0.00000} {1:0.00000} cs: {2:0.00000} cf: {3:0.00000} ps: {4:0.00000} pf: {5:0.00000}", previousSlowMa > previousFastMa && currentSlowMa < currentFastMa, previousSlowMa < previousFastMa && currentSlowMa > currentFastMa, currentSlowMa, currentFastMa, previousFastMa, previousSlowMa);
// if (previousSlowMa > previousFastMa && currentSlowMa < currentFastMa && longPosition == null)
// && CurrentFastTrend == TrendType.Up)
if (UnscentedKalman.CurrentTrend == TrendType.Up && longPosition == null)
{
if (shortPosition != null)
ClosePosition(shortPosition);
var result = ExecuteMarketOrder(TradeType.Buy, SymbolName, VolumeInUnits, label, null, TakeProfitPips);
if (result.IsSuccessful)
{
var position = result.Position;
// Print("Position SL price is {0}", position.StopLoss);
if (!double.IsNaN(StopLossPips))
{
var stopLoss = position.EntryPrice - StopLossPips * Symbol.PipSize;
ModifyPosition(position, stopLoss, position.TakeProfit);
}
// SetTrailingStop();
// Print("New Position SL price is {0}", position.StopLoss);
}
}
// else if (previousSlowMa < previousFastMa && currentSlowMa >= currentFastMa && shortPosition == null)
// && CurrentFastTrend == TrendType.Down)
else if (UnscentedKalman.CurrentTrend == TrendType.Down && shortPosition == null)
{
if (longPosition != null)
ClosePosition(longPosition);
var result = ExecuteMarketOrder(TradeType.Sell, SymbolName, VolumeInUnits, label, null, TakeProfitPips);
if (result.IsSuccessful)
{
var position = result.Position;
// Print("Position SL price is {0}", position.StopLoss);
if (!double.IsNaN(StopLossPips))
{
var stopLoss = position.EntryPrice + StopLossPips * Symbol.PipSize;
ModifyPosition(position, stopLoss, position.TakeProfit);
}
// SetTrailingStop();
// Print("New Position SL price is {0}", position.StopLoss);
}
}
}
protected override void OnStop()
{
// Put your deinitialization logic here
}
private double VolumeInUnits
{
get { return Symbol.QuantityToVolumeInUnits(Quantity); }
}
//private TrendType GetSlowTrend()
//{
// var trend = TrendType.None;
// double delta = UnscentedKalman.Neutral.Last(0) - UnscentedKalman.prevUKF;
// double delta2 = UnscentedKalman.Neutral.Last(0) - UnscentedKalman.prevUKF2;
// if (delta > Threshold || delta2 > Threshold)
// trend = TrendType.Up;
// else if (delta < -Threshold || delta2 < -Threshold)
// trend = TrendType.Down;
// return trend;
//}
private void SetTrailingStop()
{
var sellPositions = Positions.FindAll(label, SymbolName, TradeType.Sell);
foreach (Position position in sellPositions)
{
double distance = position.EntryPrice - Symbol.Ask;
if (distance < TrailingStopTrigger * Symbol.PipSize)
continue;
double newStopLossPrice = Symbol.Ask + TrailingStopStep * Symbol.PipSize;
if (position.StopLoss == null || newStopLossPrice < position.StopLoss)
{
ModifyPosition(position, newStopLossPrice, position.TakeProfit);
}
}
var buyPositions = Positions.FindAll(label, SymbolName, TradeType.Buy);
foreach (Position position in buyPositions)
{
double distance = Symbol.Bid - position.EntryPrice;
if (distance < TrailingStopTrigger * Symbol.PipSize)
continue;
double newStopLossPrice = Symbol.Bid - TrailingStopStep * Symbol.PipSize;
if (position.StopLoss == null || newStopLossPrice > position.StopLoss)
{
ModifyPosition(position, newStopLossPrice, position.TakeProfit);
}
}
}
protected void CloseAllPosition()
{
//foreach (var position in Positions.Find("MyLabel"))
//{
// // Modify/Close positions
//}
}
}
}
Hier the test parameter:
[ChartParameters]
Symbol = EURUSD
Timeframe = m1
[cBotParameters]
Source = Close
Periods = 30
Threshold = 5E-05
BrickSize = 0.0011
Quantity = 0.1
@amch
amch
10 Feb 2021, 12:21
Backtesting very slow when using nested indicators
Hi cTrader Team
I try to back test a strategy that includes a custom indicator. The custom indicator is nested as below:
protected override void Initialize()
{
// Initialize and create nested indicators
filterIndi = CreateDataSeries();
filterMA = Indicators.MovingAverage(filterIndi, Periods, MovingAverageType.Hull);
}
The back testing is really very, very slow if the custom indicator is smoothed as above.
please advise.
Christian
@amch
amch
18 Feb 2021, 15:01 ( Updated at: 21 Dec 2023, 09:22 )
RE:
PanagiotisCharalampous said:
Hello Panagiotis
The problem starts when smooth the UKF() results.
protected override void Initialize()
{
filter = new UKF();
filterIndi = CreateDataSeries();
filterMA = Indicators.MovingAverage(filterIndi, Periods, MovingAverageType.Hull);
CountBars = 0;
}
Without smoothing there is no performance issue.
Br
Christian
@amch
